digital Adjustable E Pipette Manual Single Channel Pipette Rechargeable

Extreme Accuracy Single Channel Electronic Automatic Adjustable Digital Repetitive E Pipette

Introduction:

The Single Channel Electronic Auto-Adjustable Digital Repeating Pipette is an electronic volumetric instrument designed to measure and transfer liquids precisely and safely. It can measure and transfer volumes from 0.1µl to 5000µl depending on the model.
Single-channel digital repeater E pipettes are equipped with an LCD display showing pipetted volumes and other parameters.
Volume setting is done by turning the volume setting wheel (Figure 1B). The volume range for pipetting is indicated on the pipetting key (Figure 1A).

The ForePipet pipettes are produced in 7models, covering the volume range from 0.2 µl to 5000 µl.

ForePipet is a high quality instrument with exceptional accuracy and precision. Liquid Accuracy and Precision (Repeatability)
The volume depends on the quality of the tip used. Accuracy and precision values given in the table below were obtained using matched tips. Only these tips guarantee the correct operation of the pipette and ensure accurate and precise sampling of liquids.

Description of key fuctions:


Speed key(Fig. 1E) - is responsible for changing the aspiration/discharging speed in the state of aspiration/discharging. Speed key has 5 levels, and the 1st level is the slowest.

Pipetting mode switch key(Fig. 1D) - is responsible for switching freely between manual mode and automatic pipette mode.
Pressing and holding the key in the automatic/manual pipette interface can enter the preset program or the stored program.

Adjustment wheel(Fig. 1B) - is responsible for adjusting the liquid volume in the automatic/manual pipette interface.
It can adjust the volume in manual mode (not aspirate), and the aspirate liquid is responsible for changing the direction of aspiration/discharging.
It is responsible for moving the cursor in the preset program mode.
Pipetting/enter key(Fig. 1A) - is responsible for aspiration/discharging in the main pipette mode.
The pipetting/enter key is OK key when necessary.

Description of navigation bar:

Setting the volume:

For 10µl, maximum 11µl, minimum 0.2µl, increment 0.1µl.
For 20µl, maximum 20.5µl, minimum 0.5µl, increment 0.1µl.
For 100µl, maximum 120µl, minimum 2µl, increment 0.5µl.
For 200µl, maximum 220µl, minimum 5µl, increment 0.5µl.
For 500µl, maximum 550µl, minimum 10µl, increment 2µl.
For 1000µl, maximum 1050µl, minimum 50µl, increment 1µl.
For 5ml, maximum 5.1ml, minimum 100µl, increment 10µl.
