Foregene Co., Ltd.
CHINA FOREGENE,WORLD'S FOREGENE!
 |
| Place of Origin: | China |
| Brand Name: | ForePipet |
| Certification: | ISO9001 CE |
| Model Number: | FP-121 |
| Minimum Order Quantity: | 10 sets |
|---|---|
| Price: | USD 300-330 Per Set |
| Packaging Details: | Packing with safe trans carton |
| Delivery Time: | 5-8 days |
| Payment Terms: | L/C, D/A, T/T, Western Union |
| Supply Ability: | 100000 sets per year |
| Material: | Aluminium Alloy Housing,plastic | Chargeable: | Yes |
|---|---|---|---|
| Battery: | Lithium Battery | Color: | White,green,orange,black |
| Channel: | Single | Warranty: | 2 Years |
| Product Name: | ForePipetᵀᴹ Repetitive Pipette | Application: | Laboratory Use |
| High Light: | Digital Repetitive E Pipette,Single Channel Electronic E Pipette |
||
Extreme Accuracy Single Channel Electronic Automatic Adjustable Digital Repetitive E Pipette
Introduction:
The single channel Electronic automatic adjustable Digital Repetitive E pipette is an electronic volumetric instrument designed to measure and transfer liquids precisely and safely.It can measure and transfer volumes from 0.1 µl to 5000 µl depending on the model.
The single channel Digital Repetitive E pipette is equipped with a LCD display which shows the pipetting volume and other parameters.
The setting of the volume is done by turning of the volume-setting wheel (Fig. 1B). The range of the volume of the aspirate liquid is shown on the pipetting key (Fig. 1A).
The ForePipet pipettes are produced in 7models, covering the volume range from 0.2 µl to 5000 µl.
The ForePipet is a high quality instrument which offers excellent accuracy and precision. The accuracy and precision (repeatability) of liquid
volume depend on the quality of tips used. The values for accuracy and precision given in the table below were obtained using matching tips. Only those tips guarantee correct operation of the pipettes and ensure accuracy and precision of liquid sampling.
Description of key fuctions:
Speed key(Fig. 1E) - is responsible for changing the aspiration/discharging speed in the state of aspiration/discharging. Speed key has 5 levels, and the 1st level is the slowest.
Pipetting mode switch key(Fig. 1D) - is responsible for switching freely between manual mode and automatic pipette mode.
Pressing and holding the key in the automatic/manual pipette interface can enter the preset program or the stored program.
Adjustment wheel(Fig. 1B) - is responsible for adjusting the liquid volume in the automatic/manual pipette interface.
It can adjust the volume in manual mode (not aspirate), and the aspirate liquid is responsible for changing the direction of aspiration/discharging.
It is responsible for moving the cursor in the preset program mode.
Pipetting/enter key(Fig. 1A) - is responsible for aspiration/discharging in the main pipette mode.
The pipetting/enter key is OK key when necessary.
Description of navigation bar:
Setting the volume:
For 10µl, maximum 11µl, minimum 0.2µl, increment 0.1µl.
For 20µl, maximum 20.5µl, minimum 0.5µl, increment 0.1µl.
For 100µl, maximum 120µl, minimum 2µl, increment 0.5µl.
For 200µl, maximum 220µl, minimum 5µl, increment 0.5µl.
For 500µl, maximum 550µl, minimum 10µl, increment 2µl.
For 1000µl, maximum 1050µl, minimum 50µl, increment 1µl.
For 5ml, maximum 5.1ml, minimum 100µl, increment 10µl.
