Laboratory Instrument 10.1 Inch LED Thermocycler PCR Machines 96×0.2ml

Laboratory Instrument 10.1 Inch LED Thermocycler PCR Machines 96×0.2ml

  • Laboratory Instrument 10.1 Inch LED Thermocycler PCR Machines 96×0.2ml
  • Laboratory Instrument 10.1 Inch LED Thermocycler PCR Machines 96×0.2ml
Laboratory Instrument 10.1 Inch LED Thermocycler PCR Machines 96×0.2ml
Product Details:
Place of Origin: China
Brand Name: ForeAmp
Certification: CE ISO
Model Number: SN695 SN696 SD696 SD698
Payment & Shipping Terms:
Minimum Order Quantity: 1 sets
Price: 3000
Packaging Details: Packing in safe carton box
Delivery Time: 5-8 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2000 sets per year
Contact Now
Detailed Product Description
Product Name: Thermal Cycler Pcr Machines Material: Die-casting Aluminum Housing
Input Voltage: AC100~240V Input Options Operating System: Android
WIFI Module: Built-in WIFI Module Screen: 10.1 Inch,1024x600 Pels LED
Cover System: Press Rod Type Heat Cover Certificates: CE ISO9001
Heating System: Peltier Heating Units Application: Lab
High Light:

10.1 inch LED PCR machines

,

10.1 inch LED thermocycler PCR machine

,

thermocycler PCR machine 96×0.2ml

Laboratory Instrument PCR machines China 96-PCR Test Kit LED Digital Display
Laboratory Instrument 10.1 Inch LED Thermocycler PCR Machines 96×0.2ml 0

Description:



ForeAmp series thermal cycler has

1.Android operation system and 10.1 inch capacitive touch screen .

2.Operation is very smooth and simple .

3.Air channel is in front and back and it allows machine placed side by side.

4.Self-adapting pressure hot lid makes closing lid and tightening lid in one step .

5.It has long service life peltier heating units and max. ramping rate is 8℃/s and cycle time is more than 1000,000 .

6.Wifi unit is built in and user can control many units of PCR through mobile App .



Feature


♦ Self-adaptingpressurehotlidmakesclosinglidand tighteninglidinonestep.

♦ Airchannelisinfrontandbackanditallowsmachineplaced sidebyside .

♦IthasAndroidoperationsystemand10 . 1inchcapacitive touchscreen.Ithasgraphicalmenunavigationinterfaceand operationisverysimple .

♦Built- in11standardprogramfiletemplate,canquicklyedit

therequiredfiles .

♦The running program and left time can be displayed in real time , allow to edit file when program is running .

♦ One-click quick incubation function can meet experiment’s needs such as denaturation , enzyme cutting/enzyme- link and ELISA

♦ Hotlidtemperatureandhotlidworkmodecanbesetto meetdifferentexperiment’sneed .



Laboratory Instrument 10.1 Inch LED Thermocycler PCR Machines 96×0.2ml 1

 Laboratory Instrument 10.1 Inch LED Thermocycler PCR Machines 96×0.2ml 2
Specification

Model No.

ForeAmp-
SN695

ForeAmp-
SN696

ForeAmp-SN695(384)

ForeAmpe-SD696

ForeAmp-
ST698

Capacity

96×0.2ml

96×0.2ml

384 well

6×16×0.2ml

96×0.2ml

Tube

0.2ml tube, 8 strips,
Full 96 wells plate,
Half skirt96 wells plate,


0.2ml tube, 8 strips,
Half skirt96 wells plate,
No skirt 96 wells plate

384 well plate

0.2ml tube, 8 strips,
Half skirt 96 wells plate,


Temperature Range

0-105℃

MAX. Ramp Rate

5℃/s

6℃/s

5℃/s

6℃/s

8℃/s

Uniformity

≤±0.2℃

Accuracy

≤±0.1℃

Display Resolution

0.1℃

Temperature Control

BlockTube


Ramping Rate Adjustable

0.1-5℃

0.1-6℃

0.1-5℃

0.1-6℃

0.1-8℃

Gradient Temp. Range

30-105℃



Gradient Type

Nolinear Gradient

Dynamic Gradient

Two-Dimensional Gradient

Gradient Spread

1-42℃


six zone,each zone is 0.1-5℃.

Horizontal:1-30℃
Vertical:1-24℃

Hot Lid Temperature

30-115℃

Number of Programs

20000 +(USB FLASH)

Max. No. of Step

30

40

Max. No. of Cycle

100

Time Increment/Decrement

1 Sec - 600 Sec

Temp. Increment/Decrement

0.1-10.0℃

Pause Function

Yes

Auto Data Protection

Yes

Hold at 4℃

Forever

Touchdown Function

Yes

Long PCR Function

Yes

Language

English

Computer Software

Yes

Mobile phone APP

Yes

LCD

10.1 inch,1024×600 pels

Communication

USB2.0 , WIFI

Dimensions

385mm× 270mm× 255mm (L×W×H)

Weight

10kg

10kg

17kg

Power Supply

100-240VAC ,
50/60Hz , 600 W

100-240VAC ,
50/60Hz , 600 W

100-240VAC ,
50/60Hz , 1200 W




Application



1.Gene amplification for research and clinical use

2.Qualitative PCR gene amplification

3.Fluorescent/Enzyme-Free Endpoint Quantitative DNA Gene Amplification

4.Gene amplification for other gene analysis applications such as microarrays

5.Suitable for various PCR kits at home and abroad for infectious diseases (various hepatitis viruses, Mycobacterium tuberculosis, STD sexually transmitted diseases, prenatal and postnatal care, mycoplasma, chlamydia, parasites, etc.), tumors (P53, Helicobacter pylori, etc.), scientific research (Genetic identification, bacterial virus typing, etc.)
